A) The Surface Board: Imported Teak / Maple Wood surface board finished with 21 mm thick, 50 to 110 mm width and in random length in machined tongue and groove shape on four sides. The boards will have bottom side with air pass groove.

B) The Under Frame: Made of European Fir/Spruce/Pine wood runners of 70 mm X 45 mm fixed on the bottom side with 10 mm / 18 mm EPDM thick air-cushioning pads by nails at 350 mm c/c in one direction.

C) The Installation: A vapour barrier will be placed on the leveled IPS sub-floor before laying the under frame. The runners having air cell cushioning pads will be placed on the vapour barrier in perfect level at 350 mm c/c in one direction. The surface boards will be screwed to the runners through the tongue only and will lock the screwed tongue by the groove of the adjoining boards. The ends of the boards will be locked by inserting the wooden fingers through the edge grooves and fixed with suitable adhesive. An expansion gap of 6 to 8 mm will be left open between the wooden flooring and the surrounding tiled area/wall.

D) The Finishing: After construction of the floor will be machine sanded in uniform level and finished with non-skid waterbased lacquer. Game line marking will be carried out in required colors before applying the finish coat.
